| STANDARD EQUIPPED LIST PRICE |
$573,500 |
|
|
|
|
|
|
|
|
|
| ENGINE |
|
|
|
|
|
|
|
| Manufacturer |
|
|
|
|
Lycoming |
|
|
| Model |
|
|
|
|
TIO-540-AH1A |
|
| Horsepower |
|
|
|
|
300 hp |
|
|
| Number of Cylinders |
|
|
|
6 |
|
|
| |
|
|
|
|
|
|
|
|
| PROPELLER |
|
|
|
|
|
|
|
| Manufacturer |
|
|
|
|
Hartzell |
|
|
| Number of Blades |
|
|
|
|
3 |
|
|
| Type |
|
|
|
|
Constant Speed |
|
|
|
|
|
|
|
|
|
|
| WEIGHTS |
|
|
|
|
|
|
|
| Maximum Take-off Weight |
|
|
3,600 lbs/1,633 kg |
|
| Maximum Ramp Weight |
|
|
3,615 lbs/1,640 kg |
|
| Standard Equipped Weight |
|
|
2,475 lbs/1,122 kg |
|
|
|
|
|
|
|
| Standard Useful Load (a & b) |
|
|
1,140 lbs/518 kg |
|
| a. Standard useful load is max ramp weight |
|
|
| minus standard equipped weight. |
|
|
| b. Useful load is indicated for a standard equipped aircraft. |
|
|
|
|
|
|
|
|
|
|
|
| DIMENSIONS |
|
|
|
|
|
|
|
| Wing Span |
|
|
|
|
36.2 ft/11.0 m |
|
| Length |
|
|
|
|
27.9 ft/8.5 m |
|
| Height |
|
|
|
|
8.5 ft/2.6 m |
|
| Cabin Length |
|
|
|
|
124.25 in/315.6 cm |
|
| Cabin Width |
|
|
|
|
48.75 in/123.8 cm |
|
| Cabin Height |
|
|
|
|
42.0 in/106.7 cm |
|
| Headroom (Seat to Ceiling) |
|
|
|
|
|
|
Front Seats |
|
|
|
|
38 in/96.5 cm |
|
|
Middle Seats |
|
|
|
|
35.75 in/90.8 cm |
|
|
Rear Seats |
|
|
|
|
34.50 in/87.6 cm |
|
|
|
|
|
|
|
|
|
|
| WING AREA |
|
|
|
|
|
|
|
| Wing Area |
|
|
|
|
178.3 ft2/16.56 m2 |
|
|
|
|
|
|
|
|
|
|
| FUEL AND OIL CAPACITY |
|
|
|
|
|
| Usable Fuel |
|
|
|
|
102 gal/386 liters |
|
| Oil Capacity |
|
|
|
|
12 qts/11.4 liters |
|
|
|
|
|
|
|
|
|
|
| MAXIMUM SPEED TAS |
|
|
|
|
|
| Maximum Cruise Power |
|
|
187 kts/346 km/h |
|
|
|
|
|
|
|
|
|
|
| CRUISING SPEEDS TAS |
|
|
|
|
|
| High Performance |
|
|
8,000 ft |
|
172 kts/318 km/h |
|
| Cruise Speed |
|
|
10,000 ft |
|
175 kts/324 km/h |
|
|
|
|
|
15,000 ft |
|
185 kts/342 km/h |
|
|
|
|
|
|
|
|
|
|
| CRUISING RANGE TAS |
|
|
|
|
|
| Cruising range includes 45 minute fuel reserve at |
|
| long range power plus allowance for fuel used during |
|
|
| taxi, take-off, climb at maximum climb power, cruise |
|
| and descent |
|
|
|
|
|
|
|
| Long Range |
|
|
8,000 ft |
|
950 nm/1,759 km |
|
| Cruise Power |
|
|
10,000 ft |
|
948 nm/1,755 km |
|
|
|
|
|
15,000 ft |
|
945 nm/1,750 km |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| STALL SPEED |
|
|
|
|
|
|
|
| Flaps Full Down 40° |
|
|
|
63 kias/117 km/h |
|
|
|
|
|
|
|
61 kcas/113 kn/h |
|
|
|
|
|
|
|
|
|
|
| MAXIMUM OPERATING ALTITUDE |
|
|
|
|
| Maximum Operating Altitude |
|
|
20,000 ft/6,096 m |
|
|
|
|
|
|
|
|
|
|
| BAGGAGE |
|
|
|
|
|
|
|
| Volume |
|
|
|
|
|
|
|
| Forward Compartment |
|
|
7 ft3/0.2 m3 |
|
| Aft Compartment |
|
|
|
|
17.3 ft3/0.49 m3 |
|
| |
|
|
|
|
|
|
|
|
| Capacity |
|
|
|
|
|
|
|
| Forward Compartment |
|
|
100 lbs/45.4 kg |
|
| Aft Compartment |
|
|
|
|
100 lbs/45.4 kg |
|
|
|
|
|
|
|
|
|
|
| TAKE-OFF DISTANCE |
|
|
|
|
|
| Ground Roll |
|
|
|
|
1,110 ft/338 m |
|
| Total over 50 ft Obstacle |
|
|
1,810 ft/552 m |
|
|
|
|
|
|
|
|
|
|
| LANDING DISTANCE |
|
|
|
|
|
| Ground Roll |
|
|
|
|
880 ft/268 m |
|
| Total over 50 ft Obstacle |
|
|
1,700 ft/518 m |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| STANDARD EQUIPPED LIST |
|
|
|
|
|
| Includes all listed standard equipment, FLY-AWAY-FACTORY (F.A.F.) |
| Vero Beach, FL. Dealer delivery and local taxes extra. |
| Piper Aircraft, Inc. reserves the right to make changes in |
| specifications, materials, equipment, or prices at any time without prior |
| notice or to discontinue models as required. |
|
|
|
|
|
|
|
|
|
| POWERPLANT AND PROPELLER |
|
|
|
|
| Engine-Lycoming TIO-540-AH1A 300 HP at 2500 RPM, |
|
|
|
Turbocharged, Direct Drive, 6 Cylinder, Fuel Injection, |
|
|
|
Dual Magnetos/Ignition with Shielding |
|
|
|
|
| Dynafocal Engine Mounts with Internal Dampers |
|
|
|
| Light Weight Geared Starter, 28 Volt |
|
|
|
|
| Air Filter |
|
|
|
|
|
|
|
| Full Flow Oil Coolers (Two) with Thermostatic Control |
|
|
|
| Muffler and Exhaust System |
|
|
|
|
|
| Alternate Induction Air with Manual Control |
|
|
|
|
| Oil Quick Drain |
|
|
|
|
|
|
|
| Propeller - Hartzell, 3 Blade, Constant Speed |
|
|
|
| Polished Propeller Spinner |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| FLIGHT INSTRUMENTS AND INDICATORS |
|
|
|
| Avidyne Entegra Flat Panel Display System |
|
|
|
| Primary Flight Display – Displays all required flight |
|
|
|
| instrumentation and EHSI on 10.4" screen |
|
|
|
|
|
• Solid State ADAHRS |
|
|
|
|
|
|
• Attitude |
|
|
|
|
|
|
|
|
• Airspeed |
|
|
|
|
|
|
|
|
• Altitude |
|
|
|
|
|
|
|
|
• Rate of Climb |
|
|
|
|
|
|
|
• Primary Engine Guages (MAP, RPM, Oil Press and Fuel Flow) |
|
|
• EHSI with Moving Map |
|
|
|
|
|
|
• Outside Air Temperature |
|
|
|
|
|
|
• Wind Vector |
|
|
|
|
|
|
| Multi Function Display |
|
|
|
|
|
|
• Moving Map |
|
|
|
|
|
|
|
|
• Advanced Terrain Mapping |
|
|
|
|
|
• E-Max Engine Indication System |
|
|
|
|
|
• Trip Summary |
|
|
|
|
|
|
| Engine Instrument Indicators – Displayed on MFD |
|
|
|
|
• Manifold Pressure |
|
|
|
|
|
|
• RPM |
|
|
|
|
|
|
|
|
• Turbine Inlet Temperature |
|
|
|
|
|
|
• Fuel Flow |
|
|
|
|
|
|
|
|
• Oil Temperature and Oil Pressure Indicator |
|
|
|
|
• Cylinder Head Temperatures (6) |
|
|
|
|
|
• L & R Fuel Quantity |
|
|
|
|
|
|
• Fuel Management including GPS Interface |
|
|
|
|
• Percent Power |
|
|
|
|
|
|
• Electrical System Performance |
|
|
|
|
|
• Exceedence Monitoring and Recording |
|
|
|
|
• Electrical System Performance |
|
|
|
|
| AN Heated Pitot Head and Dual Flush Static Ports |
|
|
|
| Alternate Instrument Static Source |
|
|
|
|
| Engine Hour Recorder |
|
|
|
|
|
| Annunciator Panel with Push-to-Test and Day/Night Switch |
|
|
|
• Starter Engage |
|
|
|
|
|
|
• Low Bus Voltage |
|
|
|
|
|
|
• Alternator Inoperative |
|
|
|
|
|
|
• Oil Pressure Low |
|
|
|
|
|
|
• Nose Baggage Door Ajar |
|
|
|
|
|
|
• Gear Warning |
|
|
|
|
|
|
|
• Pitot Heat Inoperative/Off |
|
|
|
|
|
|
• Flaps In Transit |
|
|
|
|
|
|
• Air Conditioning Door Open (Optional) |
|
|
|
|
• Strobe Lights |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| COCKPIT, FLIGHT AND GROUND CONTROLS |
|
|
|
| Primary Flight Controls, Dual Hytrel Control Wheels with Mic Buttons, |
|
|
Pilot’s side Elevator Trim, A/P Disconnect and CWS Buttons |
|
| Engine Controls-Pedestal with Friction Lock |
|
|
|
|
• Throttle |
|
|
|
|
|
|
|
|
• Propeller |
|
|
|
|
|
|
|
|
• Mixture (with Lock) |
|
|
|
|
|
| Alternate Induction Air |
|
|
|
|
|
| Flight Trim Controls |
|
|
|
|
|
|
|
• Rudder with Indicator |
|
|
|
|
|
|
• Stabilator with Indicator |
|
|
|
|
|
| Electric Elevator Trim Switch – Pilot Control Wheel |
|
|
|
| Stall Warning Horn |
|
|
|
|
|
|
|
| Steerable Nosewheel |
|
|
|
|
|
|
| Heavy Duty Brake System |
|
|
|
|
|
|
• Pilot's Toe Brakes |
|
|
|
|
|
|
• Co-Pilot's Toe Brakes |
|
|
|
|
|
|
• Parking Brake |
|
|
|
|
|
|
| Landing Gear, Retractable Electrohydraulic with Emergency |
|
|
|
Extension Capability |
|
|
|
|
|
| Landing Gear Warning Horn and Position Lights |
|
|
|
| Main Wheels, 6.00 X 6 Tires and Tubes, 8 Ply |
|
|
|
| Nose Wheel, 5.00 X 5 Tire and Tube, 6 Ply |
|
|
|
|
| Wing Flaps, electrically operated |
|
|
|
|
|
with four pre-selected positions (0, 10, 25 & 40 Degrees) |
|
|
| Fuel Control Selector with off/right/left guarded OFF position |
|
|
| Overhead Switch Panel: |
|
|
|
|
|
|
• Bar Guarded Push to Start |
|
|
|
|
|
• Battery Master |
|
|
|
|
|
|
• Alternator |
|
|
|
|
|
|
|
|
• Bar Guarded Electric Fuel Pump |
|
|
|
|
|
• Bar Guarded Magneto Switches |
|
|
|
|
|
• Landing/Recognition Lights |
|
|
|
|
|
• Navigation Lights |
|
|
|
|
|
|
• Strobe Light |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ELECTRICAL SYSTEM |
|
|
|
|
|
| 24 Volt, 10 Amp Hour Battery |
|
|
|
|
|
| 28 Volt, 90 Amp Alternator |
|
|
|
|
|
| External Power Receptacle |
|
|
|
|
|
| Master Switch Relay |
|
|
|
|
|
|
| Alternator Control Unit |
|
|
|
|
|
| Resettable-Type Circuit Breakers |
|
|
|
|
| Back Lighted Rocker Switches, conveniently grouped on pilot's |
|
|
|
instrument panel and overhead panel |
|
|
|
|
| Static Discharge Wicks |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| FUEL SYSTEM |
|
|
|
|
|
|
|
| Two Interconnected Fuel Tanks per Wing with 107 Gallons Total |
|
|
|
Capacity, 102 Gallons Usable |
|
|
|
|
| Flush Lockable Fuel Caps |
|
|
|
|
|
| Engine Driven Fuel Pump |
|
|
|
|
|
| Electric Emergency Fuel Pump |
|
|
|
|
|
| Fuel Quantity Gauge, Inboard Tanks, Two |
|
|
|
|
| Fuel Tank Quick Drains, Two |
|
|
|
|
|
| Fuel System Central Drain |
|
|
|
|
|
| Fuel Sampling Bottle |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| LIGHTING SYSTEMS |
|
|
|
|
|
| External Lighting |
|
|
|
|
|
|
|
|
• Wing Mounted Combination Landing and Recognition Lights |
|
|
• Navigation Lights |
|
|
|
|
|
|
• Wing Tip Comet Strobe Lights |
|
|
|
|
|
• Low Profile Red Tail Strobe |
|
|
|
|
| Cockpit Lighting |
|
|
|
|
|
|
|
|
• Instrument Panel Lighting |
|
|
|
|
|
• Avionics Dimming |
|
|
|
|
|
|
• Overhead Map Lights |
|
|
|
|
|
|
• Cockpit Entry Light |
|
|
|
|
|
| Cabin Lighting |
|
|
|
|
|
|
|
|
• Cabin Reading Lights, Four |
|
|
|
|
|
• Forward Baggage Compartment Light |
|
|
|
|
• Cabin Entry Light |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| CABIN COMFORT SYSTEM |
|
|
|
|
|
| Heater Muff, provides heat to cabin area, regulated by |
|
|
|
|
control on panel with six floor heat outlets |
|
|
|
| Windshield Defrosters and Control |
|
|
|
|
| Cabin Air Exhaust Vents, Two |
|
|
|
|
|
| Cabin Fresh Air Vents, six individually-controlled, overhead and |
|
|
|
four individually-controlled, floor mounted |
|
|
|
| Ventilation Fan with two speed settings |
|
|
|
|
|
|
|
|
|
|
|
|
|
| EXTERNAL FEATURES |
|
|
|
|
|
| Polyurethane Exterior Finish |
|
|
|
|
|
| 12” Shadowed Registration Numbers |
|
|
|
|
| Full Chemical Corrosion Protection |
|
|
|
|
| Cabin Doors, Two-Cockpit (Right Forward) and Cabin (Left Rear) |
|
|
| Tie Down Rings, Three (Retractable On Wings) |
|
|
|
| Jack Pads |
|
|
|
|
|
|
|
| Locks and Keys with Piper Logo |
|
|
|
|
| Fore and Aft Cabin and Nose Baggage Doors, Lockable |
|
|
| Utility Door for Rear Baggage Access and Cargo Loading |
|
|
| Stowable Towbar |
|
|
|
|
|
|
|
| Cockpit Entrance Step |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| COCKPIT AND CABIN APPOINTMENTS |
|
|
|
|
| Forward Cabin Door Single-Lever Locking System |
|
|
|
| Choice of four 2005 Interior Colors which includes: leather seats, |
|
|
|
designer side panels, wall to wall carpeting and headliner |
|
|
| Pilot/Co-Pilot vertically adjustable seats with inflatable lumbar |
|
|
|
support, magazine storage pockets on back of each seat with |
|
|
headrests, fore/aft and tilting adjustment with inertial reels, |
|
|
|
shoulder and safety belts |
|
|
|
|
|
| Accessory Power Point, 28 Volt |
|
|
|
|
|
| Pilot and Co-Pilot Stowable Armrests |
|
|
|
|
| Map Pockets, Two |
|
|
|
|
|
|
|
| Pilot's Storm Window |
|
|
|
|
|
| Sunvisors, Two |
|
|
|
|
|
|
|
| POH Holder |
|
|
|
|
|
|
|
| Color Coordinated Throttle Quadrant and Center Console |
|
|
| Scuff Pads, Pilot and Co-Pilot |
|
|
|
|
|
| Tinted Windshield and Windows |
|
|
|
|
|
| Window Shades on passenger windows |
|
|
|
|
| Door Closing Strap, Aft Cabin |
|
|
|
|
|
| Deluxe Six (6) Seats Lounge Interior Group with improved comfort |
|
|
|
seats, headrests for all seats, club seating arrangements with |
|
|
shoulder harness and seat belts, rear seats incorporate quick |
|
|
release feature for easy removal, refreshment console with cup |
|
|
holders, fold-down armrests on crew and rear seats and builtin |
|
|
executive writing table |
|
|
|
|
|
| Soundproofing, Quietized |
|
|
|
|
|
| Luggage Compartments with Security Straps |
|
|
|
| Rear Cabin and Hat Shelf Area, 17.3 Cu. Ft.- 100 Lbs. Capacity |
|
|
| Fuselage Nose, 7.0 Cu. Ft. 100 Lbs. Capacity |
|
|
|
| Compass Correction Card with Holder |
|
|
|
|
| Halon Fire Extinguisher |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| PRODUCT SUPPORT/DOCUMENTS |
|
|
|
|
| Manufacturers Full Two Year Limited Warranty |
|
|
|
| Initial Pilot Training Slot (1) at SimCom International Inc. - VRB |
|
|
| Pilot's Operating Handbook |
|
|
|
|
|
| Aircraft Log Book |
|
|
|
|
|
|
|
| Engine Log Book |
|
|
|
|
|
|
|
| Certificate of Airworthiness |
|
|
|
|
|
| Flight Bag |
|
|
|
|
|
|
|
| Piper Warranty/Inspection Form |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| AVIDYNE STANDARD AVIONICS PACKAGE |
|
|
|
| Primary Flight Display Avidyne |
|
|
EXP5000 |
|
|
| Multi Function Display Avidyne |
|
|
EX5000 |
|
|
| COMM/Nav/GS/GPS/#1 |
|
|
Garmin-430 |
|
| COMM/Nav/GS/GPS/#2 |
|
|
Garmin-430 |
|
| Autopilot with automatic electric trim |
|
S-TEC System 55x |
|
| Flight Director Bars |
|
|
|
|
|
|
| Integrated Altitude Pre-Selector (on PFD) |
|
|
|
|
| E-Max Engine Indicating System |
|
|
|
|
| Stand-by Mechanical Flight Instruments |
|
|
|
|
| Vacuum Pumps Removed – All electric airplane |
|
|
|
| Audio Panel with Marker Beacon |
|
Garmin GMA-340 |
|
| |
and Intercom |
|
|
|
|
|
|
|
| Digital Transponder with Traffic |
|
|
Garmin GTX-330 |
|
| |
Information System |
|
|
|
|
|
| Altitude Encoder |
|
|
|
|
|
|
|
| Control Wheel Mic Button |
|
|
|
|
|
| Avionics Master Switch |
|
|
|
|
|
| Microphone |
|
|
|
|
Telex 100T |
|
| Headset |
|
|
|
|
Telex Airman |
|
| Speaker with Mic/Phone Jacks |
|
|
|
|
|
| Static Discharge Wicks |
|
|
|
|
|
| PS Engineering Headsets (4) |
|
|
|
|
|
| Automatic Emergency Locator Transmitter (ELT) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Piper Aircraft, Inc. reserves the right to make changes in specifications, |
| materials, equipment, or prices at any time without prior notice or to discontinue |
| models as required. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
